Manistee White

HarborGate Shaker Entry System

Manistee

Model 11.1

The three-panel Shaker with a top lite, set in a full entry frame — transom above, full-lite sidelites either side.

The Manistee is the Saugatuck's slab in the Leland's frame: the three-panel Shaker door, glazed with one clear lite across the top panel, hung between two 14-inch full-lite sidelites and under a full-width transom. It is the Craftsman front entry — panelled and solid where the eye falls, glazed everywhere the light comes from. The whole unit arrives assembled in one primed PVC jamb, factory-painted White or Black, with a black 7⅝-inch threshold, black ball-bearing hinges, and double-bore prep on a 2¾-inch backset for a HarborForge handleset or smart deadbolt.

Prehung Entry DoorTransom + Sidelites

Color: White

2 available

Swatches and finishes shown are representative — actual color and texture may vary slightly. Request a sample to confirm before final selection.

See It in Your Space

Currently shown in White — change the color above to see other options.

Manistee installed in White

Built for Performance. Designed for Life.

Craftsman Proportions

One wide lite across the top panel over two tall Shaker panels — the classic front-porch door, not a slab of glass.

Light Without the Glass Door

The transom and both 14″ sidelites carry the daylight, so the entry stays bright while the door itself stays solid and private.

Complete Entry System

Slab, two 14″ sidelites, and transom arrive assembled in one jamb — a single unit to set, not three openings to align.

Manistee Specifications

ConfigurationEntry system — door slab, two 14″ full-lite sidelites, full-width transom, one jamb
GlassClear insulated glass — one lite in the top panel, full-lite sidelites, transom
PanelsTwo tall Shaker panels below the lite
CorePolyurethane foam
Bore PrepDouble bore — 2⅛″ dia., 5½″ spacing, 2¾″ backset; mortised edge latch prep, deadbolt prep, 1″ × 2¼″ strike prep
Door Slab36″ W × 80″ H × 1¾″ thick
Construction2 mm fiberglass skin on both faces over a PVC + LVL stile-and-rail frame
FinishFactory-painted — White (RAL 9003) or Black (RAL 9005)
HingesBall-bearing, black
JambPrimed PVC, 6-9/16″ depth
Threshold & Sill7⅝″ black threshold, adjustable mill-finish sill with dark cap
WeatherstripCompression
SwingLeft-hand or right-hand inswing
Brick MoldOptional 2″ PVC brick mold
PackagingPrehung unit, cartoned
